12V DC യിൾ വർക്ക് ചെയ്യുന്ന ഒരു കിടിലൻ 4 ചാനൽ ആമ്പ്ലിഫയർ ഐസി ആണ് TDA7388

TDA7388 - 4 x 45 W quad bridge car radio amplifier

Features
 High output power capability:
– 4 x 45 W / 4 ohm max.
– 4 x 26 W / 4 ohm @ 14.4 V, 1 kHz, 10 %
 Low distortion
 Low output noise
 Standby function
 Mute function
 Automute at min. supply voltage detection
 Low external component count:
– Internally fixed gain (26 dB)
– No external compensation
– No bootstrap capacitors
Protections:
 Output short circuit to gnd, to VS, across the
load
 Very inductive loads
 Overrating chip temperature with soft thermal
limiter
 Load dump voltage
 Fortuitous open GND
 Reversed battery
 ESD

Description
The TDA7388 is an AB class audio power
amplifier, packaged in Flexiwatt 25 and designed
for high end car radio applications.
Based on a fully complementary PNP/NPN
configuration, the TDA7388 allows a rail to rail
output voltage swing with no need of bootstrap
capacitors. The extremely reduced boundary
components count allows very compact sets.
